Keyless Entry Module: Service and Repair

REMOVAL

Negative Battery Cable:

1. Disconnect and isolate the battery negative cable.
2. Remove instrument panel top cover. Refer to Instrument Panel and Systems, Instrument Panel Top Cover Replacement.
3. Remove screws holding RKE module to instrument panel.

RKE Module:

4. Disconnect wire connector from RKE module.

INSTALLATION
For installation, reverse the above procedures.
